Carbon Tech Modular House by Sampangan in Indonesia

This is a pilot project for a carbon concrete building system that is affordable for low-income communities. It is estimated to be 40 per cent cheaper than conventional affordable housing in the market. The simplicity of design, modularity, knockdown system and lighter weight would also enable low-income communities that generally do not have formal construction knowledge to build their own homes, and not depend on expensive professional contractors and developers.

The building design uses a knockdown precast system that is adaptable to any site and landscape. The main building construction is well suited to any physical and climatic contexts, while the foundation can be customised to specific site conditions. These following qualities also make this building system ideal for disaster-resilient housing:

• Tensile strength helps protect during earthquakes.
• Higher fireproofing compared to conventional materials, which is good for high-density urban areas to prevent fires from spreading.
• Higher weatherproofing compared to conventional materials.

The process involved converting locally-sourced agriculture waste into activated carbon, which was then used to create the carbon concrete materials, together with raw materials from legacy landfill waste for the concrete aggregate.

Previously, the team built two houses in 2017 using the first-generation carbon concrete system (i.e., with carbon bricks). In 2021, they built a warehouse/workshop using the second-generation carbon concrete system (i.e., with a precast modular system). The team chose to build a workshop because “we wanted to test our materials first-hand with a building that we [could] use on a daily basis. Since our main operation is in waste management, it just made more sense to build the second-generation pilot building for our waste management operation,” shared Hana Purnawarman, Sampangan’s Chief Product Officer.

This project will be the first pilot house for the second-generation carbon concrete system, located in Bekasi (approximately 30 minutes from Jakarta). Even though it is close to the metropolitan area, it is still considered a remote area that is still largely underdeveloped with minimum infrastructure. The site is surrounded by local villages, where the team hired some builders from. For this particular site, the team used shallow footing foundation. The building system can also be dismantled and moved to another site.

[This is an excerpt. Subscribe to the digital edition or hardcopy to read the complete article.]

PROJECT DATA

Project Name
Carbon Tech Modular House

Location
Bekasi, Indonesia

Status
In development

Expected Completion
April 2022

Site Area
100 square metres

Gross Floor Area
36 square metres

Number of Rooms
2

Building Height
3.1 metres

Client/Owner
Sampangan

Architecture Firm
Sampangan (building system manufacturer)

Principal Architect
Hana Purnawarman

Main Contractor
Sampangan

Images/Photos
Sampangan
